Digital Thermometer – PTM-806

The PTM-806 Thermometer offers accurate and reliable temperature measurements for various applications, making it an essential tool for industrial, laboratory, and general use.

Exceptional Features of the PTM-806:

1. Wide Measurement Range: Capable of measuring temperatures from -50.0°C to 1300.0°C (-58.0°F to 2372.0°F) with high accuracy.
2. High Resolution and Accuracy: Provides 0.1°C/F resolution with an accuracy of ± (0.4% + 0.8°C) for temperatures from -50.0°C to 1300.0°C.
3. Microprocessor Circuit: Ensures high accuracy and includes special functions such as auto power off to save battery life.
4. User-Friendly Display: Features a large, bright LCD display with options for normal or reverse viewing, making it easy to read measurements in various conditions.
5. Versatile Input Socket: Standard type K input socket compatible with a full range of optional type K temperature probes, enhancing its versatility.

Technical Specifications:

Measurement Ranges:
Type K Thermocouple:
-50.0°C to 1300.0°C
-58.0°F to 2372.0°F
Resolution: 0.1°C/0.1°F
Accuracy:
-50.0°C to 1300.0°C: ± (0.4% + 0.8°C)
-58.0°F to 2372.0°F: ± (0.4% + 1.5°F)

General Specifications:

Display: Large LCD, 28 mm x 19 mm
Data Hold: Freezes the display reading
Auto Power Off: Saves battery life
Power Supply: DC 1.5V (UM4/AAA) x 4 PCs
Power Consumption: Approx. DC 6.5 mA
Operating Temperature: 0 to 50°C
Operating Humidity: Less than 80% RH
Dimensions: 175 x 40 x 40 mm (6.9 x 1.6 x 1.6 inches)
Weight: 156 g (0.34 lb)
Probe Input Socket: Standard 2 pin thermocouple socket

Included Accessories:

Type K thermocouple probe, TP-01 (1 PC)
Instruction Manual (1 PC)

Optional Accessories:

Soft carrying case with sash (CA-52A)
Type K thermocouple probes (TP-02A, TP-03, TP-04)

Versatile Applications:

Ideal for use in industrial, laboratory, and general temperature measurement applications, ensuring precise and reliable results.

Invest in the PTM-806 Thermometer for reliable and precise temperature measurements, meeting the diverse needs of various industrial and laboratory applications with precision and ease.
